Abstract
Vectorless power grid verification is a practical approach for early stage safety check without input current patterns. The power grid is usually formulated as a linear system and requires intensive matrix inversion and numerous linear programming, which is extremely time-consuming for large scale power grid verification. In this paper, the power grid is represented in the manner of domain-decomposition approach, and we propose a selected inversion technique to reduce the computation cost of matrix inversion for vectorless verification. The locality existence among power grids is exploited to decide which blocks of matrix inversion should be computed while remaining blocks are not necessary. The vectorless verification could be purposefully performed by this manner of selected inversion while previous direct approaches are required to perform full matrix inversion and then discard small entries to reduce the complexity of linear programming. Meanwhile, constraint locality is proposed to improve the verification accuracy. Experimental results show that the proposed approach could achieve significant speedups compared to previous approaches while still guaranteeing the quality of solution accuracy.
